Built on an award-winning reputation with even more capability and refinement. The same Fluid you love, with new technology and a lighter frame in a value-driven package that makes progression feel effortless from the get-go. Confidence, control, and composure for every stage of riding.
Made to Ride Better.
Top-tier design, performance-focused spec and thoughtfully integrated features across all models deliver beyond expectations. A full 6066 aluminum frame balances durability with weight savings, making it lighter than the previous generation without compromising strength.
Details
- Built to progress. Real trail performance for every stage of riding.
- Designed to deliver. Thoughtful design and proven value.
- Fit comes first. Modern geometry for every rider.
- Dialled from day one. Confidence, traction, and control without the guesswork.
- Your trail, your way. From after-work laps to all-day adventures.
- Ride Aligned™ - Suspension setup demystified.
- No Other Way Limited Lifetime Warranty. Built to last, guaranteed.
| Frame |
Aluminum Frame, 130mm Travel, UDH| R-Wheel Size Adj | Ride Aligned™ |
| Fork |
RockShox Recon RL 140mm, 44mm Offset |
| Rear Shock |
DVO Opal, 210x50mm, Std eyelet |
| Rear Shifter |
Shimano CUES SL-U6000-10R, 10sp |
| Rear Derailleur |
Shimano CUES RD-U6000, 10sp, GS |
| Crankset |
Shimano CUES FC-U6000-1, 30T, CL55, 165mm(S1,S2) - 170mm(S3,S4,S5) |
| Bottom Bracket |
Shimano, BSA 73mm |
| Cassette |
Shimano CUES CS-LG300 10sp 11-48T |
| Chain |
Shimano LG-500, 10sp |
| Front Brake |
Tektro HD-M535, 4 Piston , Resin Pads |
| Front Brake Rotor |
Tektro TR203, 203mm, 2.3mm Thickness, 6-bolt |
| Rear Brake |
Tektro HD-M535, 4 Piston , Resin Pads |
| Rear Brake Rotor |
Tektro TR203, 180mm, 2.3mm Thickness, 6-bolt |
| Brake Levers |
Tektro HD-M535 |
| Handlebar |
Norco 6061 DB Alloy, 800mm, 25mm Rise(S1,S2) - 35mm Rise(S3,S4,S5) |
| Stem |
Norco 6061, 40mm Length, 35mm Clamp |
| Seatpost |
TranzX YSI34QL , 31.6mm, 125 (S1) -150mm (S2) -170mm (S3) -200mm (S4,S5) |
| Headset |
Tapered 1-1/8"- 1.5",(ZS44/28.6 | ZS56/40) |
| Saddle |
WTB Solano Med, 142x240 mm, Steel Rails |
| Grips |
WTB Wavelength, 140mm Length |
| Seatpost Clamp |
Norco Alloy Nutted Clamp, 34.9mm ID |
| Front Hub |
Formula DC-511, 15x110mm Boost, 32h, 6-bolt |
| Rear Hub |
Formula DC-3248,12x148mm Boost, HG, 32h, 6-bolt |
| Rims |
WTB ST i30 TCS 2.0 ,30 mm, 32H, 29" |
| Front Tire |
Schwalbe Magic Mary, Trail casing, Ultra Soft , Radial, 29x2.5" |
| Rear Tire |
Schwalbe Romy, Trail casing, Soft, Radial, 29x2.4" |
| Weight |
16.9 kg (37.2 lbs) |
| Weight Size |
S3 |
