FrameSpark RC HMF Carbon Gen5, adjustable head angle and fork lock, Syncros Octopus cable integration system Gen2, BSA BB, UDH interface, 12x148mm with 55mm chainline
TravelFront: 120 mm, Rear: 120 mm
ForkRockShox SID 3P Air, Rush RL 3P Damper, 15x110mm Maxle Stealth, tapered steerer, Reb. Adj., Lockout
Rear ShockRockShox SIDLuxe Select+, 3P Lockout-Pedal-Descend, Solo Air, Reb. Adj., Lockout, bearing hardware 20x8mm, 190X45mm
Remote SystemSCOTT TwinLoc Technology, Suspension & Dropper Remote, 3 Suspension modes
Rear DerailleurShimano Deore RD-M7200 12-speed
ShiftersShimano Deore SL-M6200
CranksetShimano FC-MT520, 34T
ChainguideSpark RC Gen5 chainguide
BB-SetShimano BB-MT501 BSA
ChainShimano CN-M6100
CassetteShimano Deore CS-M6200, 10-51T
BrakesShimano BR-MT600 2-Piston
Front Disc RotorShimano RT-CL300, 180mm
Rear Disc RotorShimano RT-CL300, 160mm
GripsSyncros XC Lock-On, ready for Tubeless plug Kit Storage
HandlebarSyncros HB-M100-AL2, Alloy 6061 DB, Flat, 7°, 740mm, Syncros XC lock-on grips
H'stemSyncros XC ST-M100-AL2, -6°, 31.6mm
SeatpostSyncros dropper post SP-M302-AL2, 31.6mm
SeatSyncros Celista Cut Out
HeadsetSyncros - Acros Angle adjust +-0.5°, fork lock & cable routing Gen2 system, IS52
Front HubFormula CL-811, 15x110mm
Rear HubFormula FCL-548M, 148x12mm, Micro Spline
SpokesStainless Black
Front RimAlex Rims X-30SE 32H, Tubeless ready
Rear RimAlex Rims X-30SE 32H, Tubeless ready
Front TireMaxxis Aspen 29x2.4", 120TPI Foldable Bead, tubeless ready, EXO
Rear TireMaxxis Aspen 29x2.4", 120TPI Foldable Bead, tubeless ready, EXO
ExtrasSyncros Tool
Approx weight in KG12.9 Tubless
Approx weight in LBS28.44 Tubless
Max. System Weight130kgThe overall weight includes the bike, the rider, the equipment and possible additional luggage.
